Key Features
Pure Sine Wave Output delivers clean, stable power for sensitive appliances and equipment
High Efficiency with a peak efficiency of 94%, ensuring maximum energy conversion from solar panels and battery storage
Flexible Charging Options support both utility grid and solar MPPT charging, with a 3-step charging algorithm for optimized battery life
Surge Capacity handles 2x the rated power for 5 seconds, ideal for high-inrush load applications
Overload Protection with built-in protection against overload (5s at ≥150% and 10s at 100%-150% load) ensuring system reliability
MPPT Solar Charging supports a maximum PV array power of 2000W with an MPPT voltage range of 30-400 VDC, ensuring efficient solar energy harvesting
AC Charging Current up to 60 A for fast utility charging, with adjustable settings for various battery types (Flooded, AGM, Gel)
Versatile Voltage Input supports a wide input voltage range from 170V to 280V AC, with automatic frequency detection (50Hz/60Hz)
Short Circuit Protection with a circuit breaker for added safety in case of electrical faults
Compact & Lightweight design (4.4 kg) and compact dimensions (36 mm x 270 mm x 100 mm) for easy installation
Wide Operating Temperature Range from -10°C to 50°C, making it suitable for diverse climates
CE Certified meets international safety standards, ensuring reliability and quality
Fast Transfer Time of 10 ms for UPS and 20 ms for appliances, minimizing power disruption during switching
