Fronus META-6KW PV Inverter (Single Phase)

Fronus META-6KW PV Inverter (Single Phase)

Technical Specifications

• Model: META-6KW

• Rated Power: 6KVA / 6KW

• Phase: 1-phase in / 1-phase out

• Maximum PV Input Power: 4500W × 2 = 9000W

• Maximum DC Voltage: 500VDC

• Start-up Voltage: 90VDC

• MPPT Voltage Range: 60V – 450VDC

• MPPT Trackers / Max Input Current: 2 / 18A

Grid-Tied Operation

• Grid Feed Output: 3000W

• Nominal Output Voltage: 220 / 230 / 240VAC

• Output Voltage Range: 195.5 – 253VAC

• Nominal Output Current: 26.5A

• Power Factor: >0.99

• Efficiency (DC to AC): Up to 97%

Off-Grid Operation (AC Input)

• Start-up / Auto Restart Voltage: 170–280VAC / 180VAC (UPS Mode)

• Input Voltage Range: 90–280VAC

• Frequency Range: 50Hz / 60Hz (Auto Sensing)

• Max AC Input Current: 26.5A

General

• Dimensions (mm): 360.7 × 278 × 106

• Weight: 4.92 kg

• Communication Port: Built-in RS232 / Wi-Fi (optional)

• IP Protection: IP21

• Operating Temp: -10°C to 50°C

• Storage Temp: -15°C to 60°C

• Humidity: 5% – 95% (Non-condensing)
