Key Features
10.5KW PV Input: Wide 150–425VDC MPPT for max energy capture
Dual MPPTs: Independent strings (2/1+1) for efficient tracking
140A Charge/Discharge: Fast cycles, perfect for large systems
Parallel Ready: Stack up to 16 units, both on-grid & off-grid
Touch LCD + IP65: Vibrant screen in weatherproof casing
AC Coupling: Retrofit-friendly for system upgrades
Time-Based Battery Mode: 6 customizable time slots for charging/discharging
Generator Support: Stores DG energy for hybrid setups
Silent Operation: Under 30 dB noise, suitable for indoor use
Air Cooling: Smart thermal control from -40°C to +60°C
Advanced Protections: Overcurrent, islanding, surge, fault detection
High Efficiency: 97.6% peak efficiency with <0.5% DC ripple
Smart Communication: RS485/RS232/CAN + optional WiFi/4G
5-Year Warranty: Backed by trusted Inverex support
